●Constructed of commercial grade stainless 304.
●Stainless steel ball bearing glides to ensure easy opening and closing
●All stainless hardware, simple for maintenance.
●Zinc alloy handle or optional for handles.
●Every edge and corner are very carefully treated.
●Available in different dimensions and styles.
| Sub_Cat. | Components | |
| Material | Frame | SUS304/1.5mm |
| Front Panel | SUS304/1.0mm | |
| Back Panel | ||
| Sealed Panel for drawers | SUS304/1.0mm | |
| Outer Box | ||
| Cut-Out(inch) Dimension | W | 30.96 |
| H | 13.15 | |
| D | 18.00 | |
| Cut-Out(cm) Dimension | W | 78.64 |
| H | 33.40 | |
| D | 45.72 | |
| Overall(inch) | W | 32.00 |
| H | 15.00 | |
| D | 20.00 | |
| Overall(cm) | W | 81.28 |
| H | 38.1 | |
| D | 50.8 | |
| G.W. / CTN | LBS | 54.9 |
| KGS | 24.9 | |
| Package(inch) Dimension | L | 34.4 |
| W | 17.1 | |
| H | 22.8 | |
| Package(cm) Dimension | L | 87.5 |
| W | 43.5 | |
| H | 58 | |
| CBM/CTN | 0.2208 | |
| Cu. ft/CTN | 7.7962 | |
| Quantity for 40' HQ | 299 | |
