●All commercial grade 304 stainless steel construction.
●12,000 BTUs per burner, total 48,000 BTUs. 12,000 BTUs for back burner.
●Heavy gauge 304 stainless steel tube main burners.
●8mm stainless steel 304 cooking grates.
●Push and turn flame-thrower primary ignition system, fire crossers secondary ignition system.
●Total cooking surface 718 sq inches .
●Flame tamers minimize flare-ups while adding a grilled flavor.
●Double-lined grill hood protects outer layer from heat discoloration and maintains more heat.
●Fuel type: LP/NG.
●Grill cart available for this model.
●Inside halogen lights and control panel LED lights available.Rotisserie kit available.
| Material | 304 Stainless Steel Construction | |
| Fuel Type | LP/NG | |
| Lid | 304 S/S, 17 Guage | |
| Cooking Grid | 304 S/S, ɸ=8mm | |
| Warming Rack | 304 S/S, ɸ=6mm | |
| Heat input | S/S tube burner | |
| Control Panel | 304 S/S, 20 Guage | |
| Package | 1PC/CTN | |
| Cut-Out(inch) Dimension | 23.03 L | |
| 30.43 W | ||
| 8.46 H | ||
| Cut-Out(cm) Dimension | 58.5 L | |
| 77.3 W | ||
| 21.5 H | ||
| Overall(inch) | 23 L | |
| 32.5 W | ||
| 21.7 H | ||
| Overall(cm) | 68 L | |
| 82.5 W | ||
| 55.1 H | ||
| Ignition Mode | Piezo Igniter | |
| Main Buner | 4 | |
| BTU | 48,000 | |
| Infrared Back Burner/BTU | 12,000 | |
| Total Cooking Area/Sq.inch | 718 | |
| Cooking Area/Sq. inch | 576 | |
| Warming Area /Sq. Inches | 142 | |
| G.W. / CTN | 118 LBS | |
| 53.5 KGS | ||
| N.W. /CTN | 103 LBS | |
| 46.5 KGS | ||
| Package(inch) Dimension | 35.82 L | |
| 27.95 W | ||
| 24.40 H | ||
| Package(cm) Dimension | 91 L | |
| 71 W | ||
| 62 H | ||
| CBM/CTN | 0.4006 | |
| Cu. ft/CTN | 14.1405 | |
| Quantity for 40' HQ | 156 | |
